Rebuild's Corvette 72 350 except LT-1 Air Dam |
Die cut sponge rubber, 1" thick & 36" long with
a stepped pattern contouring with the underside of the 350 hoods. It covers
the top of radiator support from fender to fender & steps down on either
end. Uses 2 PIF. |
|
Part # |
72 350 except LT-1 Radiator to Hood Air Dam |
1274408 |
|
The BLUE ARROWS shown above illustrate sharp edges or corners that are found on
original blueprints and the Dr
REBUILD reproduction. The bogus reproduction
lacks these features. Instead they have these areas radiused as curves.
Since these air dams are flattened by the hood after installation, you could
never used an original part to determine the correct profile. Apparently
Blem Products alleged "years of research and many original samples"
did not include making a die from a factory blueprint. |
